Cast Iron Steel Scaffolding Accessories Wing Nut Anchor Nut For Tie Rod / Anchor Plate

Cast Iron Steel Scaffolding Accessories Wing Nut Anchor Nut For Tie Rod / Anchor Plate

  • Cast Iron Steel Scaffolding Accessories Wing Nut Anchor Nut For Tie Rod / Anchor Plate
  • Cast Iron Steel Scaffolding Accessories Wing Nut Anchor Nut For Tie Rod / Anchor Plate
  • Cast Iron Steel Scaffolding Accessories Wing Nut Anchor Nut For Tie Rod / Anchor Plate
Cast Iron Steel Scaffolding Accessories Wing Nut Anchor Nut For Tie Rod / Anchor Plate
Product Details:
Place of Origin: Ningbo China
Brand Name: NC891
Certification: ISO 9001,CE
Model Number: 891
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Packaging Details: Pallet
Delivery Time: 25 days
Supply Ability: 200,000 pcs
Contact Now
Detailed Product Description
Product Name: Wing Nut Application: Formwork
Material: Cast Steel, Ductile Iron Type: Formwork Tie Nut
Finish: Galvanized HS Code: 7308400000
High Light:

scaffolding parts

,

formwork accessories

Cast Iron Steel Scaffolding Accessories Wing Nut Anchor Nut For Tie Rod / Anchor Plate



Description



Wing nuts and Tie rods as a whole facility are used widely in formwork construction. There are single wing nut, butterfly wing nut, two anchor wing nut, three anchor wing nut, combination wing Nut. Because of this structure, wing nuts can be easily tightened and loosened by hand without any tools. Wing nuts have casting and forging types by processing technology , common thread size is 17mm / 20mmon thread size is 17mm/20mm.



Application



It is high quality construction formwork fastener and has been used to many large projects like high rise building, bridge, hydroelectricity, nuclear power projects.

Features


1. High tensile strength.
2. High process precision, precise thread.
3. Surface treatment: It can be electroplated, hot dip galvanized or according to the drawing, sample or special requirement of clients.



Product Details



Item Construction Hardware
Name Anchor Nuts For Formwork Scaffoldings
Raw material Ductile Iron, Steel
Process Precision Casting or Sand Casting
Diameter of Plate 70mm,80mm,90mm,100mm,110mm
Suitable for with 15/17mm tie rod
Unit weight 0.28/0.35/0.45/0.56/0.61/0.65/0.66/0.7/0.73kg
Types Butterfly nut, Combination nut, Hex nut, Steel cone
Surface finish silver or Golden cold Galvanized or by painted
Tensile Resistance 90-190KN
Marking(Logo) any logo is available on the nuts
Package by Woven bag and steel pallet
Delivery time 25 days upon the prepayment
Production Capacity 3000pcs per day
Payment term T/T or L/C


Cast Iron Steel Scaffolding Accessories Wing Nut Anchor Nut For Tie Rod / Anchor Plate 0

About Us


we are a manufacturer of construction formwork accessories and building fastener such as form tie, pin, wedge pin, hex nut, flat tie, wall tie, tie rod, wing nut, scaffold coupler, u-clip, expansion anchor bolt, chain roller, implosion nut, cutting wire and other non-standard fastener most of them used in building channel bridge construction to fix formwork.

We can provides services in designing of Scaffolding and Formwork products. We provide Technical services to clients in order to assist them with their requirements.

Our main objective is to provide the most secure, economical and easy to use scaffolding and formwork systems to satisfy our clients requirements.



Any Other Related Products We made



Ringlock, Cuplock, Kwikstage, Frame Scaffolding
Formwork clamp, Adjustable Shoring Prop, Traffic Barrier.



Main Market



South America, Eastern Europe, North America, Southeast Asia, Africa, and Arabic country.



Our Advantages



1. A professional scaffolding products and hardware manufacturer with 25 years of experience.

2. Strong production capacity.

3. High quality and competitive price.

4. Strictly Quality Control system.
5. 100% finished products are checked before shipment.
6. Provide Technical services to clients in order to assist them with their requirement.
7. Experienced Technical Team.
8. Can ask for Technical Details of products.





Cast Iron Steel Scaffolding Accessories Wing Nut Anchor Nut For Tie Rod / Anchor Plate 1







FAQ



Q1. What do you do?
A: We design and manufacture formwork and scaffolding products used for pouring concrete structure in the field of housing, high rise buildings, towers, sports stadiums, bridges, hydropower stations, industrial structures etc.



Q. Is the sample free?
Yes

Q. How about the delivery?

We ensure your goods can be delivered safely and on time.
